It is suitable for the cleaning of the rust layer, thick-layer paint, deep oil stain, rough surface and weld cleaning, which will affect the surface of the substrate. The efficiency is very high.
Application | |||
Rust Removal | Oxide Removal | Molding Cleaning | Surface Preparation |
Coatings Removal | Weld Pre-treatment | Gluing Pre-treatment | Removal of Oil and Grease |
Paint Removal | Surface Cleaning | Stain Removal | Surface Roughening |
Tool Cleaning | Historic Restoration | Selective Paint Removal | Precise Cleaning |
1)Powerful, short pulses, fast moving laser pulses act on the surface of the target, producing tiny plasma ruptures, shock waves, thermal stress, etc., causing surface materials to sublimate and evaporate.
2)The focused laser beam is capable of accurately evaporating surface objects or dirt.
3)Laser cleaning is suitable for metal surfaces. The treated and optimized laser beam does not alter metal properties or damage those laser treated surfaces. The precisely tuned laser beam acts only on the coating, residual residue or oxide, and does not harm the underlying parent metal surface.
4)By adjusting other parameters, the laser beam is able to achieve the desired cleaning effect accurately and easily.
Equipment model | LXC-50 | LXC-100 | LXC-200 | LXC-500 | LXC-1000 |
Laser working medium | Yb-doped fiber | ||||
Laser power | 50W | 100W | 200W | 500W | 1000W |
Laser wavelength | 1064nm | ||||
Pulse frequency | 20-100KHz | 20-100KHz | 20-200KHz | 20-50KHz | 20-50KHz |
Cooling method | Air cooling | Air cooling | Air cooling | Water cooling | Water cooling |
Dimension | 760mmX780X790mm | 1100x950x700mm | |||
Total Weight | 30kg | 60kg | 65kg | 130kg(Including Water tank) | 140kg(Including Water tank) |
Total power | 350W | 600W | 1000W | 1800W | 2000W |
Different configuration and design maybe has little difference | |||||
Scan width | 10-60mm | ||||
Optional | Hand/automatic | ||||
Working temperature | 5-40 degree |
