| Machine Model | LX9TQ |
| Power of Generator | 1000-3000W |
| Chuck | Front and rear dual pneumatic chucks |
| Positioning Accuracy | 1500*3000mm(Other size can be customized ) |
| Maximum Speed | 70m/min |
| Chuck speed | 80r/min |
| Applicable pipe specifications | Round tube 20mm-80mm |
| Tube length | 6050mm |
| Silo load-bearing | 3T |
| Single maximum weight | 200kg |
| Voltage | 380V±10%50HZ |
Good rigidity, high precision, no deformation during the life cycle;
Welded aluminum collet board, formed through high precision process. Good weight and good dynamic performance
![[LX9TQ]Front Pull Type Metal Tube Cutting tube laser cutting for stainless steel copper carbon steel](https://www.lxshow.net/data/upload/ueditor/20220525/628d7ee067777.jpg "[LX9TQ]Front Pull Type Metal Tube Cutting tube laser cutting for stainless steel copper carbon steel")
It adopts an pneumatic clamp design on both sides and it can modulate the center automatically.The diagonal adjustable range is 20-220mm(320/350 is optional)
![[LX9TQ]Front Pull Type Metal Tube Cutting tube laser cutting for stainless steel copper carbon steel](https://www.lxshow.net/data/upload/ueditor/20220426/6267b33f244d9.jpg "[LX9TQ]Front Pull Type Metal Tube Cutting tube laser cutting for stainless steel copper carbon steel")
Automatic pneumatic chuck, adjustable and stable, clamping range is wider and clamping force is larger. Non - destructive pipe clamping, fast automatic centering and clamping pipe, performance is more stable. The chuck size is smaller, rotation inertia is low, and dynamic performance is strong. Self-centering pneumatic chuck, gear transmission mode, higher transmission efficiency, long working life and high work reliability.
![[LX9TQ]Front Pull Type Metal Tube Cutting tube laser cutting for stainless steel copper carbon steel](https://www.lxshow.net/data/upload/ueditor/20220426/6267b350d5b9f.jpg "[LX9TQ]Front Pull Type Metal Tube Cutting tube laser cutting for stainless steel copper carbon steel")
It employs intelligent tube support design, which can solve the deformation problems in the process of long tube cutting
![[LX9TQ]Front Pull Type Metal Tube Cutting tube laser cutting for stainless steel copper carbon steel](https://www.lxshow.net/data/upload/ueditor/20220426/6267b35ee6160.jpg "[LX9TQ]Front Pull Type Metal Tube Cutting tube laser cutting for stainless steel copper carbon steel")
System is equipped with servo motor, boot to homework, do not need to return to zero operation, power outages, a key recovery cutting operation
![[LX9TQ]Front Pull Type Metal Tube Cutting tube laser cutting for stainless steel copper carbon steel](https://www.lxshow.net/data/upload/ueditor/20220426/6267b4cd5f47c.jpg "[LX9TQ]Front Pull Type Metal Tube Cutting tube laser cutting for stainless steel copper carbon steel")
Intelligent Alarm System
It can detect anomalies in advance, reduce hidden dangers, and double the effect of abnormal detection of equipment
Stroke intelligent protection
Detect whole process of cutting head working, quickly feedback the risk and stop it. Double protection with fixed limit to improve equipment and personal safety and reduce risk
![[LX9TQ]Front Pull Type Metal Tube Cutting tube laser cutting for stainless steel copper carbon steel](https://www.lxshow.net/data/upload/ueditor/20220426/6267b4db9e86a.jpg "[LX9TQ]Front Pull Type Metal Tube Cutting tube laser cutting for stainless steel copper carbon steel")
lt will automatically in cutting process adjust the focus which can realize the best cutting effect of different thickness of metal
![[LX9TQ]Front Pull Type Metal Tube Cutting tube laser cutting for stainless steel copper carbon steel](https://www.lxshow.net/data/upload/ueditor/20220426/6267b3dab4366.jpg "[LX9TQ]Front Pull Type Metal Tube Cutting tube laser cutting for stainless steel copper carbon steel")
![[LX9TQ]Front Pull Type Metal Tube Cutting tube laser cutting for stainless steel copper carbon steel](https://www.lxshow.net/data/upload/ueditor/20220426/6267b4e5b4f96.jpg "[LX9TQ]Front Pull Type Metal Tube Cutting tube laser cutting for stainless steel copper carbon steel")
